This model provides the files for a 1:10 scale Lanz Raupenbulldog. The project is no longer actively maintained, but the author notes it remains one of their most reliable models despite early development quirks.
**Purpose**
The model is designed to be used as a full RC-model, a load, or for individual parts.
**Practical Uses**
When configured as an RC vehicle, the model can clear snow or coarse dirt. Note that the included dozer blade features a closed bottom/flat design, which may prevent the user from dumping all material.
**Included Parts**
The file set includes various components such as the driver's cab (Fuehrerstand), tracks (Tracklink), sprocket, return rollers, motor covers, and an optional dozer blade (Schaufel). The tracks are designed to utilize M2 bolts with an internal nut. The model requires external hardware and electronics, specifically a motor and gearbox originally made for the Henglong 3898 Sherman, a 6-channel remote, a 2-channel ESC, and a standard 2S LiPo battery.
**Printing and Assembly Guidance**
File names are in German, though STEP files are provided to assist with placement. The author notes that some parts may feature butt-joints due to previous design choices. For assembly, anything not held together by screws can likely be glued. For blade articulation, the author suggests hot-gluing a servo into the cab and running a wire from the servo horn to the blade, using a tension spring to pull the blade down so the servo only performs lifting work.
