This model is a conversion of an official DJI website asset from .glb to .stl format. The author provides this version for use in creating accessories or for 3D printing purposes. Included parts: dji fpv.stl Note: The author states that these models are intended for printing or accessory design and will not fly.
This model set features digital representations of the DJI Mavic 3 drone. The author states these models were sourced from the official DJI website and converted from .glb to .stl formats. Purpose The models are intended for creative projects, such as designing or making custom accessories. Practical Uses Users can utilize these files for 3D printing or as a base for accessory design. The author notes that these printed models are for display or prototyping purposes only and will not fly. Included Parts The download includes two specific files: - DJI mavic 3 folded.stl - DJI mavic 3 unfolded.stl
Purpose: This part acts as a rollbar to protect the mechanism located between the servo and the turning under the servo. Practical Uses: It is intended as a quick part replacement rather than a long-term solution. The author notes it is not as aesthetically pleasing as the original Traxxas part. Included Parts: - mechanism_cover.stl
Purpose: These brackets are designed to hold a Raspberry Pi and a Raspberry Pi camera on the Lego 42099 (4X4 X-treme Off-Roader). The setup is intended for remote control driving, allowing for WiFi control and a remote video feed to address the limited range of Bluetooth control via the official Lego app. 1 Practical Uses: The author suggests mounting the Raspberry Pi camera on the roof for better visibility and placing the Raspberry Pi inside the cabin. The design is compatible with Raspberry Pi model 3B+ and Raspberry Pi camera rev1.4. Included Parts: - CameraBracket.stl - PiHolder A.stl - PiHolder B.stl
RC Servo Wire Strap Purpose This model is designed to tame and secure RC servo wires. The part utilizes a support structure that creates a pattern intended to lightly grip the wires in place. Practical Uses It is used in radio control applications to organize and manage servo wiring. Included Parts - wire bracket.stl - Requires an M1.5 screw for use. Printing and Assembly Guidance The author suggests printing 5, 6, or more units at a time due to their small size. When necessary, the brim should be peeled off. Suggested print settings: - Print Quality: 0.12 SUPER - Build Plate Adhesion: Brim - Brim Line Count: 4 - Generate Support: TRUE - Z Seam Alignment: Random - Infill Density: 100%
This model is a bottom access hatch designed specifically for the FT Simple Scout XL RC airplane. It serves as a removable door to provide access to the internal components of the aircraft through the bottom of the fuselage. This design is a remix of the original model found at https://www.thingiverse.com/thing:4739776. Included Parts: - ft simple scout xl bottom access door.stl - Frame_1.STL Note: This listing does not provide specific printing parameters, material recommendations, or assembly instructions. Users should refer to the original source or their own flight hardware requirements for compatibility and installation guidance.
Purpose: This is a work in progress design for the Xpress Execute FT1S intended to provide more side protection than the original. 1. Practical Uses: The bumper arches out to offer increased protection to the sides of the vehicle. 2. Included Parts: bumper.stl, bumper V2.stl. 3. Printing/Assembly Guidance: The author reports the model is made in TPE with 85A flex. Recommended settings include a wall line count of 5, no top or bottom layers, 40% infill, and a Tri-Hexagon or honeycomb infill pattern.
Xpress Execute FT1S Bumper, Final Purpose This model is a replacement bumper designed for the Xpress Execute FT1S. According to the author, this version is intended to perform better than the original bumper, specifically maintaining durability during racing and hard crashes. Practical Uses This part is intended for use in RC racing environments. The author reports that the bumper successfully withstood 7 hours of track use and hard crashes. Included Parts - Bumper_Final_version.stl Printing and Assembly Guidance The author recommends using Ninjaflex 85A material. Suggested print settings include: - Top/Bottom layers: 0 - Walls: 1 - Infill: 50% The author suggests scaling up the Z-value to 12mm, or to your desired height.
This model serves as a placeholder tire designed for a 1/10 scale rock crawler. The author states it was modeled using a combination of different sources. Practical uses include serving as a component for a 1/10 scale RC truck. The design is intended for an 8mm hex hub featuring a 3mm center hole. The dimensions are described as a 14x10 rim with a 35x12 tire. Included files: - rc tire.stl - CFFFP_rc tire.gcode
This model serves as a workaround design for the RadioLink RC4GS On/Off switch, intended for use if the original switch cap has been misplaced. Practical uses include replacing a lost switch cap on a RadioLink RC4GS transmitter. The author provides a STEP file to allow others to use the design as a base for creating improved versions. Included files: - rc-switch.step - rc-switch-v7.stl
Basic Scx24 Trailer Purpose This model is a basic trailer designed specifically for the SCX24. The author created this design to provide a simplified alternative to complex trailer kits that require numerous bearings, bolts, nuts, and multiple files. Practical Uses This trailer serves as a lightweight accessory for the SCX24 platform. To attach the hitch to an SCX24 Deadbolt, the author recommends using an open frame hole located behind the rear shock tower. A paper clip or similar item is slid through this hole, and the hitch is then placed onto the middle of the paper clip. Included Parts The model consists of the following STL files: - Axel3.stl - Bed.stl - BedToCar.stl - AxelMountx2.stl - HitchForScx.stl - TrailerTire.stl Assembly Guidance Assembly requires glue and random screws. To facilitate the hitch attachment on the SCX24 Deadbolt, you may need a tool to make a hole in the plastic frame to allow the paper clip to pass through. Attribution: Author via source text.
Purpose This model serves as a reinforcement for the Freewing F4-Phantom elevator servo, designed to be glued over the servo to keep it securely in place. Practical Uses It is used to stabilize the elevator servo within the aircraft. Included Parts - Freewing-F4-Hoehenruderservohalter.stl Printing and Assembly Guidance The author suggests printing with PETG or PLA. High infill is not required, as 2 outlines are sufficient. IMAGE PRESENTATION The cover is an original AI-assisted MESHOPIA illustration based on the supplied geometry, showing a proposed finish during workshop inspection. It is not evidence of a manufactured, fitted or tested part. Tools and surrounding objects illustrate context and are not included.
Marker Pen Drawing Bot Purpose This model is a drawing bot designed to create random circular patterns. The author created this version using components repurposed from an RC boat toy. Practical Uses It serves as a remote-controlled drawing robot. The author notes that the bot's movement can be controlled using the remote controller from the original RC boat. Included Parts The model files include: - Bracket.stl (three required) - Top.stl - Base.stl - Weight.stl (multiple sizes required) - Mount.stl - Weight.step Printing and Assembly Guidance This is described as an easy print. Assembly requires three Brackets and several different sizes of the Weight. When adjusting the size of the Weight, the user should adjust the axle hole accordingly. The author suggests using different Weight sizes to manage two specific issues: using a weight that is too large may cause the motor to melt the PLA, while a weight that is too light may cause the bot to simply spin without drawing effectively.
R9M slim+ antenna mount Purpose This model is designed as an antenna mount specifically for the Frsky R9M slim+ receiver. Practical Uses It is intended to be glued to a plane to secure the receiver's antenna. The design utilizes friction to hold the antenna in place, meaning no glue is required for the antenna itself. Included Parts - antana_mount.STL Assembly Guidance The mount should be glued to the aircraft. The antenna is held within the mount via friction alone.
Tire Purpose This model is a replacement or custom tire designed for use with RC cars. Practical Uses It is intended for RC vehicle applications where a tire with specific dimensions is required for fitment. Included Parts - 1x Tire (tire.stl) Specifications - Inside diameter: 55mm - Outside diameter: 70mm
This model is a simple front lower arm designed for the Thunder Tiger Tomahawk 4WD nitro RC car or its Carson clone. It is intended for use in onroad 4WD applications. 120-300 words when facts suffice, otherwise be concise.
This camera mount is designed for the GEPRC Cinebot 30. It is intended to replace the original part on the drone. Practical uses include mounting a GoPro (8, 9, 10, 11, 12) or a DJI Action 2 to the Cinebot 30. Included files: - Cinebot30 Camplate Gopro.stl - Cinebot30 Camplate Gopro.step Printing and assembly guidance: The author suggests printing the part in PETG or PC. The reported weight when printed in PC is 5.3g. IMAGE PRESENTATION The cover is an original AI-assisted MESHOPIA illustration based on the supplied geometry, showing a proposed finish during workshop inspection. It is not evidence of a manufactured, fitted or tested part. Tools and surrounding objects illustrate context and are not included.
Frsky TD R10 mount Purpose This model is designed to serve as a dedicated mount for a Frsky TD R10 receiver within an RC plane. Practical Uses It is intended for RC aircraft hobbyists looking to secure a Frsky TD R10 receiver in place during flight. Included Parts - TD_R10_Mount.3mf Printing/Assembly Guidance Refer to the provided .3mf file for printing specifications. No specific assembly instructions are provided in the source text.
This model is a cone designed for use on trails, suitable for both indoor and outdoor environments. Practical uses include trail marking or obstacle placement. Included files: - cone for rc.stl The author states that the size of the cone can be adjusted within your slicer software.
This 3D model is an unfinished prototype intended to serve as a conceptual basis for magnetic dampers for RC cars. Inspired by a concept from Fast & Furious 6, the model is provided primarily for editing and redesigning purposes rather than as a finished functional product. Practical Uses The model is intended to act as a starting point for creators to design and develop high-quality, strong magnetic shock absorbers, specifically for applications such as Traxxas RC cars. The author suggests using the file to iterate on the idea to create a more effective suspension system. Included Parts The model file includes a prototype magnetic suspension design (prototype_magnetic_suspension.stl). Printing and Assembly Guidance The design requires 2.5x8mm magnets. The author specifies that magnets must be placed in a repelling orientation to function. Note that the author describes the current state of the model as unfinished, lacking sufficient springiness for light RC cars, and containing significant filing errors.
Purpose: This is a modeler version of a 7.4v 1000mah RC battery holder. Practical uses: Designed for organizing or holding RC car batteries. Included parts: - Module_Rc_Car_battery_holder.stl - Module_Rc_Car_battery_holder_left_Rail.stl - Module_Rc_Car_battery_holder_Right_Rail.stl - Module_Rc_Car_battery_holder_Right__Left_Rail.3mf
Packing for Metal 370 Motor Gearbox Purpose This model is a packing component designed to be placed between metal parts to improve the quality of the seal. Practical Uses It is intended for use with a Metal 370 Motor Gearbox. The author suggests that using this component can double speed. Included Parts - packing.stl - packing v2.stl - packing_0.2mm_PLA_MK3S_7m.gcode Printing and Assembly Guidance The author suggests printing the component in flexible filament (flex) for optimal results. The author has also indicated availability to design the entire case upon request via message.
Steering Spacer for TRX4M Purpose This model is a steering spacer designed for use when installing a Reefs Micro 99 Servo paired with a Reefs Micro short horn on a TRX4M. Practical Uses It is intended to provide fitment between the steering horn and the steering link. The author specifically designed this to work with a TRX4M setup that utilizes a metal steering link, the Reefs Micro 99 servo, and the Reefs Micro horn. Included Parts - TRX4M Steering Space.stl Printing and Assembly Guidance The author reported successful use of PLA for this part, noting that it is holding well. However, the author suggests that stronger materials may provide better durability for this application.
Honeycomb wall RC remote mount Purpose This model is designed to store a pistol-style RC controller on a honeycomb storage wall. It is specifically made for the FS-GT3C remote. Practical Uses It serves as a dedicated mounting solution for hobbyists looking to organize their RC equipment using a honeycomb wall system. Included Parts - pulto hex init.stl Assembly Guidance The mount attaches to a 4x1 hex wall insert (consisting of 4 hexes, with 1 containing a screw hole). It is secured to the wall using two screws into two holes.
Mini Drone Frame Purpose This model is a mini drone frame designed specifically for use with a cheap Amazon drone. Practical Uses It serves as a replacement or custom frame for small-scale RC flight applications. Included Parts - drone v2.stl - drone motor.stl
Purpose This battery tray is designed to be suspended by the cross bars of a Dlux 2.2 rock crawler rig. It allows the battery to be slid across the cross members to adjust left/right weight distribution and tucks the battery further away from potential harm. Practical Uses The tray is sized specifically for a GensAce 850mAh 3S battery. According to the author, using this setup in their rig results in only 1% more weight on the front axle compared to placing the battery directly on the front axle. Included Parts - DLux Battery Tray.stl Printing/Assembly Guidance The author printed this part on a Prusa using supports, though they suggest it might be possible to print without them.
This model is a drone frame designed for RC flight applications. It serves as the structural body for a drone assembly. Practical uses include building a custom remote-controlled drone platform. Included files: drone body.stl
This model is a functional roof box/cargo box designed for a 1/10 scale RC connection. The author suggests using a piece of paper clip to facilitate the joint connection. Practical uses include adding cargo storage to 1/10 scale RC vehicles. The author reported printing these parts using a SOVOL SV06 printer with PL filament. Included files: cargo base.stl cargo top v2.stl cargo top.stl roof rack.stl
Traxxas Slash 2WD Motor Holder Purpose This model is designed to hold a Titan 550 12T RC motor securely during maintenance or initial use. It provides a stable base for the motor while it is being cleaned or during the break-in process. Practical Uses It serves as a dedicated stand for hobbyists working on Traxxas Slash 2WD setups, ensuring the motor remains upright and stationary during cleaning tasks or while running through its break-in period. Included Parts - single vent motor stnad.stl Printing/Assembly Guidance No specific printing or assembly instructions are provided in the source data.
RC Tire Prep Bottle Holder Purpose This model is designed as a specialized holder for RC tire preparation bottles. It serves as a themed organizational tool for hobbyists working on RC car maintenance. Practical Uses It is intended to hold tire preparation liquids used in the RC hobby, providing a dedicated space for these bottles during use or storage. Included Parts - khd prep bottle skull.stl Printing and Assembly Guidance No specific printing parameters or assembly instructions are provided in the source documentation.
Foam Plane Skewer Washer Purpose This model is a skewer washer designed for use in DIY foam RC plane models. Its primary function is to help guide and hold skewers in place while reducing wear on the foam material. Practical Uses These washers are intended for RC aircraft construction. The author provides an example of this part being used on the FT Simple Cub from FliteTest. Included Parts - Skewer_Washer.3mf - Skewer_Washer_Modified.3mf Assembly Guidance To install, first make a skewer hole in the foam to align the washer. Apply a few dabs of hot glue onto the washer, then push it into the foam board until it is flush with the surface.
This model is a tool holder and tray designed to keep RC tools organized and ready for use. It is intended for hobbyists working with RC cars, RC planes, or racing equipment. Included files: - rc tool holder and tray.stl
rock terrain tyles Purpose These files are designed to create an indoor track for 1:24 scale RC crawlers. The model consists of terrain tiles featuring integrated rock elements. Practical Uses They are intended for use as indoor obstacle courses or driving surfaces for small-scale remote-controlled rock crawlers. Included Parts - rockwall.stl - stones.stl Printing/Assembly Guidance No specific printing or assembly instructions are provided in the source text.
This model consists of modified gearbox components designed for increased durability. The modifications include a hexagonal shape for the gear hub and gear housing, as well as a larger torque damper to handle higher torque loads. Practical uses include RC car applications requiring beefed-up CV joint and gearbox components. Included files: - MAIN GEAR HUB - C06 - HEXAGONAL.stl - CV GEAR HOUSING - C02 - HEXAGONAL.stl - TORQUE DAMPER - C05 - STRONGER.stl - CV CAGE - C03 - CLOSED.stl - CV CAGE - C03 - OPEN.3mf Printing/Assembly Guidance: The CV cages are beefed-up versions that can be printed in various materials. A closed version of the CV cage is available specifically for printing in TPU.
Zino Tx control stick protection Purpose This model is designed to provide protection for the control sticks of the Hubsan Zino remote control, specifically for the HT016B transmitter model. Practical Uses It is used as a protective cover for the sticks on the Hubsan transmitter used with the Zino drone to prevent damage or wear. Included Parts - ProtetorSticksZinoTxHT016B.stl Printing Guidance Based on the author's report, the model can be printed using PLA with the following settings: - Nozzle Temperature: 220 °C - Plate Temperature: 60 °C - Infill: 20%
This model is a bed rack designed for a 1/10 scale RC car, specifically compatible with the Hero F150 from JDmodel. Practical uses include adding cargo storage or scale accessories to the bed of the Hero F150 RC vehicle. Included files: - F150 bed rack v1.stl
Purpose These pulleys are designed to convert a 1/10 RC drift car to use a belt drive first-stage in place of gears. Note that using a belt drive first stage will reverse wheel rotation, requiring a gear swap in the transmission or ESC reprogramming to correct. Practical Uses The pulley profiles are HTD 3mm, though the designer recommends using them with S3M belts to reduce friction. For a 15T/40T pulley setup, a 50T belt is suggested as a starting point. The pinion is intended to press onto a 14T/48P pinion gear. Included Parts - Pinion - 15T.step - Spur - 40T.step - S3M 15T YinYang.stl Printing and Assembly Guidance Print components true to size for best performance. The spur features an 8x16mm bolt circle to fit most drift chassis. The pinion is configurable from 14-20T and the spur is configurable from 36-48T.
Nazghul5 V2 ELRS Antenna Mount Purpose This model is a TPU mount designed to hold an ExpressLRS (ELRS) receiver on an analog Nazghul quadcopter. While specifically created for this frame, the author notes it will almost certainly work on other models. Practical Uses It is used in FPV drone builds to provide a secure, flexible mounting solution for ELRS receivers, helping to integrate digital control systems into analog-configured frames. Included Parts - ELRS.stl Printing and Assembly Guidance No specific printing parameters or assembly instructions are provided in the source text.
SCX24 upgrade 180/320 motor Purpose This model is a motor conversion designed for the Axial SCX24. The upgrade aims to replace the original motor, which the author reports often burns out under long-term load, with a unit that provides higher speed and better performance in extreme conditions, such as mud. Practical Uses This conversion is intended for RC crawler enthusiasts looking to improve the drive unit's durability and power output during heavy-duty or high-load driving scenarios. Included Parts - HGD1_14t_Pinion.stl - aJprwKyApLG (4).stl - Kolo v převodovce Originál Axial.stl Printing and Assembly Guidance The author recommends printing the gears in PET-G, noting that it proved most effective during testing. While PLA was used initially, PET-G was found to be superior. The author also tested ASA but noted that the small gears deformed during the printing process because the ASA could not cool fast enough; therefore, PET-G is the recommended material.
Purpose These models are digital representations of the DJI Air 3, converted from official .glb files to .stl format by the author. Practical Uses The models can be used for creating accessories or for 3D printing. The author notes that these printed models are not intended for flight. Included Parts - air3_unfolded.stl - air3_folded.stl Assembly Guidance A tutorial is provided at https://vimeo.com/775340586.
Purpose This is a slip-in mount designed for the Spektrum AR637T receiver. It allows dual antennas to be routed through one of four holes each to achieve a required 90-degree angle between them. Practical Uses The holes are sized for PTFE tubing. The author suggests that adding 0.2 mm to the tubing diameter when adjusting hole sizes provides a good fit. Included Parts - Spektrum AR637T RC Rcvr Antenna Mount-AntennaMountBody.stl - Spektrum AR637T RC Rcvr Antenna Mount.fcstd Printing and Assembly Guidance The author printed this using white ASA on a Bambu X1C with BambuStudio's 0.16 Optimal setting and normal support. The model should be placed with the hole end down on the build plate. Note that cleaning support material from the holes may take a few minutes.
Servo Halterung 40mm (Calmato) Purpose This model is a servo mount designed specifically to accommodate a 40mm servo. According to the author, this plate is suitable for use with the Kyosho Calmato Sport. Practical Uses It is intended for use in RC aircraft applications, specifically as a mounting solution for 40mm servos within the Kyosho Calmato Sport airframe. Included Parts - Servo 40mm.stl Printing/Assembly Guidance No specific printing or assembly instructions are provided in the source text.
XT60 Halter für Jet Modell Purpose This model is a specialized holder designed for XT60E connectors. It is intended for use in RC jet aircraft to organize and secure electrical connections. Practical Uses It is suitable for installation within RC jets, providing dedicated mounting points for various components. The holder features specific labeling to assist with organization: 'RX1' and 'RX2' are designated for batteries, while 'FW' is designated for the landing gear. Included Parts - XT60 Halterung.stl Printing/Assembly Guidance Not provided in the source text.
Festo 4mm Ventil (2-fach) Purpose This model is a bracket designed to hold two Festo 4mm valves. According to the author, it is intended for use during the refueling process of RC aircraft. Practical Uses It is specifically suited for scenarios where two different fluids are required, such as refueling with kerosene in one valve and smoke oil in the other. Included Parts The listing includes the following file: - Festo Ventil 4mm.stl Assembly Guidance Not specified.
Tankstation (RC) Purpose This model is a refueling station designed to accommodate the Miracle pump from Engel Modellbau. It is specifically intended for use with canisters featuring a DIN61 thread. Practical Uses It serves as a specialized holder for RC-related fueling tasks, specifically compatible with setups involving the Miracle pump for managing fluids such as gasoline or kerosene in RC planes and jets. Included Parts The model consists of two parts provided in the Tankstation.stl file. Assembly Guidance Users must glue both parts together to complete the holder. The design includes a specific cutout intended for a cable tie adhesive socket to secure the pump. Additionally, a piece of hook-and-loop fastener should be placed under the pump to facilitate fastening the battery.
Tamiya XV02 Rally Car Stand Purpose This low profile stand is designed specifically for the Tamiya XV02 Rally Car. Its primary purpose is to attach directly to the chassis, making the vehicle easy to display on a shelf. Practical Uses It serves as a dedicated display solution for RC enthusiasts looking to showcase their Tamiya XV02 models in a compact, shelf-friendly manner. Included Parts - Tamiya XV02 Rally Car Stand.stl Printing and Assembly Guidance According to the author, the model should be printed at a 90-degree angle. Recommended print settings include a 0.10 layer height and 0.30 infill. The estimated print time is just over 2 hours.
Purpose This 7mm wide spacer is designed for use with M3 screws. While intended for RC cars, the author notes it can be used for other applications. Practical Uses The spacer is described as being suitable for offsetting shocks from a chassis. Included Parts - 7mm spacer for M3 screw (1).stl
Purpose These 10mm hex adapters are designed to allow the use of 10mm hex wheels from the Spanish company Bycmo on other RC models. Practical Uses The adapters are intended for LC-racing or WLtoys vehicles in 1/14 and 1/12 scales. The author notes that 1/10 scale models also use the same 10mm hex size. Included Parts - RC hex10.stl - RC hex10 4ks.gcode Printing Guidance The author recommends using PLA filament with a 0.4mm nozzle. Suggested settings include a nozzle temperature of 210°C, a bed temperature of 45°C, a layer height of 0.2mm, and a first layer height of 0.3mm.
