Electrónica

Explora modelos 3D de Electrónica publicados en Meshopia. Consulta los archivos, la información de impresión disponible y la licencia de cada ficha.Abrir todos los filtros →
Vista de Brazo de recambio para servomotor MG995

Brazo de recambio para servomotor MG995

Brazo u horn imprimible para sustituir el accesorio de salida de un servomotor MG995. Es una pieza de unión entre el eje del servo y el mecanismo que se desea mover; no incluye el servomotor ni la varilla de mando. La compatibilidad indicada por la fuente se limita al MG995 y debe comprobarse con la unidad concreta, especialmente en el estriado central y la fijación. Preparación, compatibilidad e impresión El autor propone un 50 % de relleno. Ese dato no acredita la resistencia de una impresión particular. Antes de montar, comprueba que el estriado entra sin forzarlo, que el tornillo retiene la pieza y que el brazo no roza durante todo el recorrido. Prepara primero una prueba de encaje y evita compensar un ajuste incorrecto apretando más el tornillo.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Palanca para mando Xbox y simulador de drones

Palanca para mando Xbox y simulador de drones

Accesorio que se coloca sobre el stick de un mando Xbox para utilizarlo como palanca en un simulador de drones. Su función es modificar el agarre del mando durante la simulación; no convierte el mando en una emisora de radiocontrol ni añade comunicación directa con un dron. La fuente no identifica todas las revisiones de mando compatibles. Preparación, compatibilidad e impresión El autor indica PLA y soportes. Compara el alojamiento con el stick de tu mando y comprueba que el accesorio no pulse botones ni limite el recorrido. Retira los soportes con cuidado en las zonas de enganche. Empieza con una prueba de ajuste sin forzar el stick; configura después sensibilidad y calibración dentro del simulador.

Tecnología
Sin probar
Material
PLA
Dificultad
Sin especificar
Vista de Pieza de sujeción del conector de batería para Air65

Pieza de sujeción del conector de batería para Air65

Pieza plástica de sustitución para la zona del conector de una batería utilizada en un Air65. El autor la desarrolló después de romper la pieza original durante una intervención. La publicación no identifica la batería exacta ni aporta un procedimiento eléctrico de reparación, por lo que no se presenta como un recambio universal ni como una instrucción para abrir una celda. Preparación, compatibilidad e impresión Comprueba la geometría del conector y el espacio disponible con el equipo desconectado. La impresión no debe comprimir la batería, exponer contactos ni sustituir aislamiento dañado. No se especifican material ni parámetros de impresión. Si la batería presenta daños, la pieza impresa no la convierte en segura ni apta para seguir utilizándose.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de FRC Main Breaker Shroud (1/4 inch bolt version)

FRC Main Breaker Shroud (1/4 inch bolt version)

This model is an FRC Main Breaker Shroud designed to accommodate a 1/4 inch bolt. Purpose The shroud is intended to facilitate the installation of a 1/4 inch bolt into the top of an FRC Main Breaker. Practical Uses It is designed to work with a 7/16 inch socket for the installation process. Included Parts - FRC Main Breaker Shroud .25in bolt.stl - FRC Main Breaker Shroud .25in bolt.step Printing/Assembly Guidance The author used pink Elegoo PLA filament for the print.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Yamaha NX-N500 Remote Control Holder

Yamaha NX-N500 Remote Control Holder

Yamaha NX-N500 Remote Control Holder Purpose This model is a dedicated holder designed specifically for the Yamaha NX-N500 remote control. Its primary function is to provide a secure storage location for the device. Practical Uses This holder can be used to keep the Yamaha NX-N500 remote in a fixed, accessible position, preventing it from being misplaced. Included Parts - NX-N500 Yamaha Remote Holder.stl Assembly Guidance According to the author, the holder is designed to be mounted using adhesive backing.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de DJI FPV Remote Controller 3 stick protector

DJI FPV Remote Controller 3 stick protector

DJI FPV Remote Controller 3 stick protector Purpose This model serves as a simple protector for the DJI FPV Remote Controller 3 sticks. Practical Uses It is designed to act as a gimbal lock for the controller's joysticks. Included Parts - DJI Controller 3 gimble lock v3.stl Printing and Assembly Guidance For optimal results, use a 0.4mm nozzle. The author recommends printing the model in either PLA or ABS. Please note that this model requires supports during the printing process.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Remote control holder

Remote control holder

Remote Control Holder Purpose This model is a wall-mounted holder specifically designed to store and organize a remote control. Practical Uses It serves as a dedicated mounting solution to keep a TV or device remote easily accessible while reducing clutter on surfaces. Included Parts - porta telecomando.stl Printing and Assembly Guidance No specific printing or assembly instructions are provided in the source data.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Sharp XL-B510 Remote Controller Wall Mount Holder

Sharp XL-B510 Remote Controller Wall Mount Holder

sharp remote controller holder Purpose This model is a wall mount holder specifically designed to store and organize a Sharp remote controller. Practical Uses It serves as a dedicated mounting solution for the Sharp XL-B510 remote controller, providing a fixed location on a wall to prevent loss or clutter. Included Parts * sharp holder.stl Printing/Assembly Guidance No specific printing or assembly instructions are provided in the source data.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de ESParto Cyberdeck ESP32 Remote Control

ESParto Cyberdeck ESP32 Remote Control

The Esparto is an ESP32-based transmitter designed for controlling robots and buggies via WiFi or Bluetooth. The enclosure features an OLED screen for status indication and debugging, two dual-axis joysticks with integrated buttons, and three additional function buttons. It also includes a switched external-facing USB port to power extra or extended devices and a 10mm grid of 3mm holes for mounting future modules. The design provides easy access to the ESP32 serial port for programming and the buttons on the ESP32 board. Included Parts: - 1x ESP32-WROOM-32D development board - 1x 0.91" I2C OLED screen - 1x Battery charger board (3.3v output) for 18650 cell - 2x Dual-axis joystick modules - 1x Mini rocker switch - 3x Mini momentary push button switches - Various 2.5mm standoffs Recommended Hardware: - 6x 8mm nylon spacers for button mounts (or 6mm with an additional 2mm nut) - 4x 6mm nylon spacers for battery module - 3mm nuts used as spacers for joysticks - Various M3 screws (author used M3x10 throughout) Printing/Assembly Guidance: The author printed this on a Bambu Labs X1 using a 0.2mm layer height throughout, though it can be printed on any machine. An updated OLED screen mount includes sockets for screw shafts to prevent wire interference when fitting the lid.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Remote Control Holder

Remote Control Holder

This model is a remote control holder designed to organize and store remote controls. Practical uses include keeping remote controls in a single, accessible location. Included parts: - remote-control-v3.stl The author specifies that the model was printed using chromatik phosphorescent PLA filament.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de FC adapter 26.5mm to 20mm

FC adapter 26.5mm to 20mm

Fc adapter 26,5 mm to 20mm Purpose This model is an adapter designed for an FC (Flight Controller) stack. It is intended for use in scenarios where the stack dimensions are smaller than the drone frame size. Practical Uses It serves as a mounting solution to bridge the gap between different stack mounting standards, specifically adapting a 26.5mm mounting pattern to a 20mm requirement within an FPV drone setup. Included Parts - Adaptador fc 26.5mm to 20mm.stl Printing/Assembly Guidance Not provided.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Monster Guts - PWM DC Motor Speed Controller Box

Monster Guts - PWM DC Motor Speed Controller Box

Monster Guts - PWM DC Motor Speed Controller - Box Purpose This model is a dedicated enclosure designed specifically for the PWM DC motor speed controller sold by Monster Guts (https://monsterguts.com/products/pwm-dc-motor-speed-controller). Practical Uses It serves as a protective housing for the speed controller, featuring integrated cut outs to accommodate the control dial and wire management. The design includes a zip tie slot at the bottom to facilitate mounting. Included Parts - PWM DC Motor Speed Controller Box (.3mf) - PWM DC Motor Speed Controller Box (.stl)

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Two Bladed Propeller Snap Fit

Two Bladed Propeller Snap Fit

Two Bladed Propeller Snap Fit Purpose This model is a two-bladed propeller originally designed for the VOLANTEXRC RC Plane - P51 Mustang Ready to Fly. It is intended to fit other brands, such as LEAMBE. Practical Uses It serves as a replacement or custom part for RC planes and similar electronics-based hobbyist aircraft. Included Parts - Two Bladed Propeller.stl Printing and Assembly Guidance For optimal performance, the author recommends using light filaments such as PLA, ABS, or PETG, noting that other materials may increase drag. For best use, the bottom of the propeller should be sanded. Printing settings recommended by the author include: - Layer height: 0.16mm or lower - Infill: 0% - Wall thickness: 0.8mm (2 lines) - Support and adhesion should be used during the printing process.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de MK4 Swerve Module Grease Shield - FRC

MK4 Swerve Module Grease Shield - FRC

MK4 Swerve Module Grease Shield - FRC Purpose This design is intended to provide the functional benefits of a swerve drive system while preventing grease spatterings during operation. Practical Uses It is designed for use in FRC (FIRST Robotics Competition) applications involving swerve drive modules to contain lubricant and reduce mess. Included Parts - Back Piece.3mf - Left Side.3mf - Front Piece.3mf - Right Side.3mf - SwerveShild_0.2mm_PLA_MK3S_13h51m.gcode Printing and Assembly Guidance The author states that this design is easy to install and does not require any disassembly of the module during the installation process.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de 775 DC Motor Holder

775 DC Motor Holder

Purpose: This model is a holder designed specifically for a 775 DC motor. The author states it can be used in any project that utilizes a 775 motor. Practical Uses: It is intended for use in various projects that require a mounting solution for a 775 DC motor. Included Parts: - 775 DC Motor Mount.stl

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de DC Socket Box

DC Socket Box

DC Socket Box Purpose This model is a housing designed to hold a screwed DC socket. It features two holes to accommodate the socket installation. Practical Uses According to the author, this housing was created to provide power for a monitor and a 3D printer LED light. Included Parts - DC Socket box.stl Printing/Assembly Guidance Not provided.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de XT30 female connector

XT30 female connector

XT30 female connector Purpose This model is designed to provide an easy-to-print XT30 female connector suitable for various types of RC models. Practical Uses It can be used in RC applications, such as RC planes, to facilitate cable connections. Included Parts - XT30 femmina2.0.stl Printing and Assembly Guidance The author explicitly states: DO NOT SCALE the model.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de CR Scan Ferret SE Rugged Box

CR Scan Ferret SE Rugged Box

CR Scan Ferret SE Rugged Box Purpose This model is a rugged storage box designed specifically to store the Creality Ferret SE. Practical Uses To provide a protective housing for the device, the author suggests utilizing the foam that is included in the original packaging to secure the unit inside the box. Included Parts - Box_-_Latch_1.stl - Box_-_Bottom.stl - Box_-_Lid.stl Assembly Guidance The author suggests using M3 screws to serve as the pins for the assembly.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de BC-250 Heat sink mount

BC-250 Heat sink mount

BC-250 Heat sink mount Purpose This model is a custom heat sink mount designed for the BC-250. It is intended to facilitate the installation of a specific aftermarket heat sink on the device. Practical Uses Users can utilize this mount to adapt a compatible heat sink to the BC-250. The design is intended to work in conjunction with an Intel clip bracket and various hardware components. Included Parts This listing includes the digital file: bc-250 - mk7.stl. Note that physical hardware, such as the Intel clip bracket, M4 bolts, M4 nuts, or the heat sink itself, are not included. Assembly Guidance The author reports using an Intel clip bracket and hardware from the stock heat sink for assembly. The mounting holes are sized to accommodate two different fastening methods: using M4 bolts to self-tap from the bottom, or using screws through the holes secured with M4 nuts on the top.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de (Remix) Yaesu FT-891 Radio and Yaesu FC-50 Tuner Armor / Rails for small printers

(Remix) Yaesu FT-891 Radio and Yaesu FC-50 Tuner Armor / Rails for small printers

This model is a remix of armor rails designed for the Yaesu FT-891 radio and the Yaesu FC-50 tuner. The original design has been split into smaller components specifically to accommodate users with smaller print beds, such as an Ender 3 V2. Purpose and Practical Uses The purpose of these rails is to provide armor/rail protection for the Yaesu FT-891 radio and the FC-50 tuner. By splitting the parts, the model allows for the printing of larger accessories on standard-sized hobbyist printers. Included Parts The files included in this set are: - FT_891 Tuner Armor Rail 1.stl - FT_891 Tuner Armor Rail 2.stl - FT_891 Radio Armor Rail 1.stl - FT_891 Radio Armor Rail 2.stl Printing and Assembly Guidance For printing, the radio rail requires supports due to the bend in the handle. The other parts should print without supports, provided the files are oriented with the recess facing upwards. If you need to print parts for the opposite side, you must mirror the files in your slicer software. Regarding assembly, if you are not using the screws provided with the FC-50 kit, be sure to note the maximum screw length required.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Generic DC Power Supply Wall Mount

Generic DC Power Supply Wall Mount

Generic DC Power Supply Wall Mount Purpose This model is a case designed to enclose a generic 12V power supply unit (PSU) and mount it to a wall. It is intended to fit most standard standalone power supplies used in 3D printing, such as Mean Well models. The design features ventilation holes, though one side lacks holes to prevent dust collection inside the PSU. A specific hole is included to allow visibility of the status indicator light. Practical Uses This case is used for organizing and securing power supplies on a sturdy surface. It allows for easy access to connectors while keeping the unit enclosed. The design includes a cap to close off the open side of the case. Included Parts - Power Supply Mount - Case - Power Supply Mount - Cap Printing and Assembly Guidance For printing the case, use tree supports and an infill of ≥ 15% with ≥ 2 walls. When printing the cap, it is recommended to print at under 100% scale depending on your printer's accuracy and filament. Users should consider the thermal properties of their chosen filament against the heat generated by the PSU. To assemble, disconnect the power, install the case on a surface using screws (5mm diameter holes), and slide the PSU in so connectors are accessible and ventilation patterns match. If using the cap, snap it into place via friction fit. To remove the PSU, disconnect power and push the unit from the covered side; if the cap is installed, it should pop off with the force of the PSU.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Remote Holder (Brennenstuhl) RCT CE1 CR

Remote Holder (Brennenstuhl) RCT CE1 CR

Remote Holder (Brennenstuhl) RCT CE1 CR Purpose This model is designed as a dedicated holder for the Brennenstuhl RCT CE1 CR remote control. Practical Uses It serves as a storage solution to keep the Brennenstuhl RCT CE1 CR remote organized and easily accessible. Included Parts - Brennenstuhl Fernbedienung - RCT CE1 CR.stl

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de CASE ENCLOSURE for XY-7025 DC-DC step down changer converter with XT-60 connectors

CASE ENCLOSURE for XY-7025 DC-DC step down changer converter with XT-60 connectors

This model is a case enclosure designed for the XY-7025 DC-DC step down changer converter, which features XT-60 connectors. Purpose and Practical Uses The enclosure serves to house the XY-7025 converter. It includes integrated legs intended to provide better ventilation for the device during operation. Included Parts The model files include the main case components, XT-60 holders, and legs. Specific files provided are: - XY7025-CASE.stl - XY7025-CASE-viko-1.stl - XT-60-DRZAK-LEP-NEW.stl - Nohy-spunty.stl - XT-60DRZAK-KABEL-NEW-FIN.3mf - XT-60DRZAK-KABEL-NEW-FIN.stl Printing and Assembly Guidance The author recommends using PCTG filament for printing. The case consists of four parts that must be assembled using acrylic super glue. Regarding the XT-60 holders, the author suggests sticking them in a position that you find most suitable for your specific needs.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de DC Motor Placeholder

DC Motor Placeholder

DC Motor Placeholder Purpose This model is a DC motor placeholder intended for use within CAD designs that require the inclusion of DC motors. It serves as a spatial reference within a digital assembly. Practical Uses This file is designed for digital modeling and design workflows. It allows users to account for the presence and volume of a motor within a larger CAD project. As noted by the author, this is not a physical print, but a placeholder for design purposes. Included Parts - DC Motor placeholder.stl Printing/Assembly Guidance This model is not intended for physical printing or assembly. The author explicitly states: "THIS IS NOT A PHYSICAL PRINT JUST A PLACEHOLDER".

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Case for 12V 0.8A DC PWM Speed Controller Module

Case for 12V 0.8A DC PWM Speed Controller Module

Case for 12V 0.8A DC PWM Purpose This model is a protective chassis designed for a 12V 0.8A DC PWM single-wire fan temperature control speed controller. It is intended for use with computer noise reduction modules featuring an NTC B50K 3950 sensor. Practical Uses This case is used to house the speed controller module, providing a structured enclosure for electronic components used in fan temperature control and noise reduction applications. Included Parts The download includes four STL files, each featuring a different wall thickness to suit different printing preferences or structural requirements: - PWMv12_case_1.6mm.stl - PWMv12_case_1.4mm.stl - PWMv12_case_2mm.stl - PWMv12_case_1mm.stl

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Holder for HW-140 DC-DC Volt LCD Display

Holder for HW-140 DC-DC Volt LCD Display

Holder for HW-140 DC-DC Volt LCD Display Purpose This model is designed to provide a permanent mounting solution for a HW-140 DC-DC Volt LCD Display. It was specifically developed to monitor the battery voltage of a 160 GS (y1963) scooter without interfering with normal vehicle operation. Practical Uses It can be used to install a voltmeter under the seat of a vintage Vespa scooter or other mobile devices to monitor electrical levels. The setup includes a push switch to allow the user to activate the measurement on demand. Included Parts The assembly consists of two main components: - A case for the voltmeter that clips into a second mounting part. - A mounting part designed to be attached to the scooter using the two original nuts used to fix the fuel tank. Printing and Assembly Guidance The model is provided in two files: Holder_HW140DCDC_3a.stl and Case_HW140DCDC_3a.stl. Regarding printing, the author states that the top part of the case should be printed with support everywhere. No specific printing instructions are provided for the lower part.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de RC522 Cover

RC522 Cover

RC522 Cover Purpose This model is a mountable cover designed specifically for an RFID RC522 module. The author utilized a backless design to ensure the module remains as close as possible to the RFID tag to facilitate signal pickup. Practical Uses While designed for the RC522 module, the author specifically utilized this cover mounted in Lauan plywood for an escape room puzzle application. Included Parts The files provided include: - RC522 Cover.stl - RFID Logo color.stl - RC522 Cover with logo.stl Assembly Guidance The cover features screw holes with a diameter of 3mm. The design is backless to allow for maximum proximity between the module and the RFID tag.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Universal AC Web Remote Case

Universal AC Web Remote Case

Universal AC Web Remote Case Purpose This custom 3D-printed enclosure is designed for the ACWebRemote project, an open-source ESP32-based WiFi IR blaster. It provides a neat, sturdy, and minimalist housing to transform an ESP32 development board into a reliable Wi-Fi-powered universal remote for air conditioners. Practical Uses Designed for wall-mounting or shelf placement, the case is intended to house a device that controls various AC brands (including Carrier, Daikin, Fujitsu, Gree, Hitachi, Mitsubishi, Panasonic, Samsung, and others) via a browser or Home Assistant integration. The design supports dual front-facing IR LEDs to provide wide coverage. Included Parts The model includes files for the enclosure components: esp32_slim_top_2.stl, esp32_slim_bottom.stl, and esp32_slim_top.stl. Printing and Assembly Guidance Printing is intended for FDM/FFF printers (tested on Bambu Lab A1) using PLA filament. Recommended settings include a 0.2 mm layer height, 15–20% infill, and printing in a face-down orientation without supports. To assemble, insert the ESP32 development board (30-pin layout, Micro-USB) with soldered IR LEDs into the enclosure. Route the USB cable through the opening located at the bottom for power connection.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de XT60 to DC socket size: 5.5 x 2.1 mm

XT60 to DC socket size: 5.5 x 2.1 mm

This model is designed to repurpose a 12V power supply by providing a way to connect it without cutting off the existing barrel connector. It serves as a modification of an existing XT60 enclosure project. Practical uses include converting a standard DC barrel jack power supply into a format compatible with XT60 connections. The design is specifically sized for a 5.5 x 2.1 mm DC socket. The provided files include: - dc_power_jack_3p5x1p35mm (bottom).3mf - dc_power_jack_3p5x1p35mm v1 (Top).3mf This project is a slight tweak to the XT60 enclosure found on MakerWorld (https://makerworld.com/en/models/757261-xt60-enclosure#profileId-691653).

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Gopro mount Vanquish H10 Optic

Gopro mount Vanquish H10 Optic

Gopro mount Vanquish H10 Optic Purpose This model is a roof rack designed specifically for the Vanquish H10 Optic, featuring an integrated GoPro mount. Practical Uses It is intended for hobbyist or RC use to provide a mounting point for a standard GoPro Quick mount on the vehicle's roof. Included Parts - gopro mount1.stl - gopro mount.stl Assembly Guidance The roof rack is mounted to the rails using M2 screws. It is designed for compatibility with standard GoPro Quick mounts.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de DC female housing

DC female housing

DC female housing designed for installation into a 15 mm hole. Purpose The purpose of this model is to provide a housing for a DC female connector. Practical Uses This component is intended for use in electronic projects or enclosures requiring a secure mounting point for a DC female power input through a 15 mm diameter opening. Included Parts The model consists of two separate files: dc part 1.stl dc part 2.stl Printing and Assembly Guidance Assembly requires the two parts provided in the files to create the complete housing for the 15 mm hole.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de How to Mechatronics RC Transmitter Case

How to Mechatronics RC Transmitter Case

How to Mechatronics RC Transmitter Case Purpose The purpose of this 3D project is to provide a 3D printable enclosure for a transmitter. The design aims to allow users who possess the corresponding PCB to house the controller within a functional case that offers a comfortable grip. Practical Uses This model is intended for hobbyists and makers who have acquired the transmitter PCB and require a protective and ergonomic housing to turn the electronics into a usable handheld controller. Included Parts The project includes the following file: - RC Transmitter Case v2.stl Printing and Assembly Guidance No specific printing parameters or assembly instructions are provided in the source text. Users should refer to their own hardware requirements for the PCB to ensure proper fitment.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de FC 9imod F722 + ESC 4in1 60A

FC 9imod F722 + ESC 4in1 60A

Purpose This model provides a digital representation of the 9imod F722 flight controller paired with its 60A 4in1 ESC. The model includes the main electronic micro-components to facilitate integration into larger design projects. Practical Uses The model is intended for use in digital projects where the physical dimensions and presence of the 9imod F722 flight controller and ESC are required for spatial planning or assembly visualization. Included Parts - 9imod F722 + ESC 4in1 60A.stl - 9imod F722 + ESC 4in1 60A.step

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de AMD BC-250 with CPU Cooler Mount Adapter

AMD BC-250 with CPU Cooler Mount Adapter

AMD BC-250 with CPU Cooler Purpose This model is a CPU cooler mount adapter designed specifically for the BC-250 board. According to the author, implementing this cooler setup reduced maximum temperatures from 92°C to 72°C during testing. Practical Uses It is intended to facilitate the mounting of a specific CPU cooler (referenced via https://a.co/d/gyw5dgC) onto the BC-250 board to improve thermal management. Included Parts The download includes the following file: - BC250-Cooler-Mount.stl Assembly Guidance To mount the cooler to the 3D printed adapter, use the longer Intel brackets. The assembly requires M4 nuts and bolts for mounting.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Wheel

Wheel

Wheel Purpose This model is a basic wheel designed for a wide variety of applications. According to the source, it is intended to be used for "lots of things." Practical Uses Based on the provided tags, this wheel is suitable for projects involving toys, remote control (RC) vehicles, cars, trucks, motorcycles, or motorbikes. Included Parts - wheel.stl Printing/Assembly Guidance No specific printing or assembly instructions are provided in the source text.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de CC - CYD Centauri Carbon Monitor Modification

CC - CYD Centauri Carbon Monitor Modification

This model is a modification of the CC MINI.STL file provided with the Centauri Carbon printer, designed to house a 2.8" Cheap Yellow Display (CYD) for monitoring printer status. If the riser and glass cover are omitted, the case can function as an informative pencil holder. Practical uses include mounting a CYD flush with the case face to display status messages. The design features a hole for a USB cable to exit the back and an extended top section. Included parts: - cc-monitor-ldr: Case with a hole for an LDR (or LED on newer CYD models) - cc-monitor-plain: Basic case without an LDR/LED hole - cc-riser-logo: Riser featuring the Elegoo logo - cc-riser: Plain riser - glass: Cover with a handle Required hardware: - Right-angle USB (e.g., USB-micro right-angle cable assembly or a USB-C right-angle adapter with a standard USB-C cable). Note: Do not power the CYD with two cables simultaneously. - Two 6mm M3 bolts - Two M3 nuts Printing and assembly guidance: - All parts require supports. - The glass cover is designed at 0.4mm thickness (two 0.2mm layers). For a clearer transparent handle, the author suggests printing very slowly with a small layer height, such as 0.1mm. The handle color can be changed after the first 0.4mm of printing.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Rocket model

Rocket model

Rocket model Purpose This is a two-piece rocket model designed with fins and aerodynamic features. The design includes internal space intended to accommodate electronics if the user chooses to integrate them. Practical Uses According to the author, the model can be used as a sculpture or as a housing for electronic components/gadgets. Included Parts - Circular Pattern 06.stl - Circular Pattern 04.stl Assembly Guidance The model consists of two pieces that can be attached to one another.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de XT60H-M Screwable Adapter with Editable FreeCAD File

XT60H-M Screwable Adapter with Editable FreeCAD File

XT60H-M Screwable Adapter with Editable FreeCAD File Purpose This compact screwable adapter is designed specifically to hold an XT60H-M connector. It features two mounting holes, allowing the adapter to be fastened to a panel, plate, or custom project. Practical Uses This part is suitable for DIY builds, custom housings, and adapter plates where a secure, mounted XT60H-M connection is required. Included Parts - XT60-Male-Adapter.stl - XT60-Male-Adapter.fcstd (Editable FreeCAD file) Printing and Assembly Guidance The connector is intended to be fixed into the printed part using super glue or a similar adhesive, as it does not utilize a mechanical snap fit. Note that this design is intended specifically for the XT60H-M variant and has not been tested with other XT60 variants or similar connectors. If necessary, dimensions can be adjusted using the provided FreeCAD file.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de DeepCool AN600 adapter for AMD BC-250

DeepCool AN600 adapter for AMD BC-250

DeepCool AN600 Adapter for AMD BC-250 Purpose This 3D-printable mounting solution is designed to facilitate the installation of a DeepCool AN600 cooler onto the AMD BC-250 motherboard. Practical Uses This adapter allows users to repurpose or utilize the DeepCool AN600 low-profile cooler specifically with the AMD BC-250 hardware platform. Included Parts This model requires the Intel mounting brackets that are included with the DeepCool AN600 kit. The following hardware is necessary for installation: - 4x M3 x 12mm bolts - 4x M3 x 20mm bolts - 8x M3 nuts Printing and Assembly Guidance To prevent warping or sagging under thermal load, it is recommended to use high-temperature, stiff filaments such as ASA, ABS, or Carbon Fiber/Glass Fiber reinforced PETG (CF-PETG / GF-PETG). Suggested print settings include: - Walls: 4 - Top/Bottom Layers: 6 - Infill: 30% Cubic High wall counts and a cubic infill pattern are suggested to ensure the structural rigidity required for consistent mounting pressure.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de Under Counter/Shelf Mount for DC Supply with Clip Organizer

Under Counter/Shelf Mount for DC Supply with Clip Organizer

Under Counter/Shelf Mount for DC Supply with Clip Organizer Purpose This model is designed as an under-counter or shelf mount for a DC power supply. It includes an integrated clip organizer for improved workspace management. Practical Uses It is specifically designed to accommodate the SPS-3010 0-30V power supply or an equivalent model. The mount allows the device to be suspended beneath a shelf or counter surface. Included Parts - DC Supply Mounting Bracket (STL file) Printing and Assembly Guidance To complete the installation, print this part twice. Place one unit at the front and the second unit at the back in the same orientation. The assembly is held in place by rubber feet. For printing, place the part flat on the build plate and use a 0.2mm structural profile. No supports are necessary for this print.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de DIY VTX and fan holder

DIY VTX and fan holder

This model set provides components for a DIY VTX (Video Transmitter) and cooling fan mounting solution designed for FPV applications. Purpose The purpose of these models is to create a mounting setup for a VTX that includes integrated cooling to manage high operating temperatures. Practical Uses These holders are intended for FPV (First Person View) setups. The author suggests using a fan to prevent the VTX from overheating, as excessive heat may melt the plastic components. Included Parts The set includes two STL files: - vtx holder.stl - fan holder (1).stl Printing and Assembly Guidance The author reports using PLA for these prints. The fan holder is designed to accommodate a 4 x 4 cm cooling fan. WARNING: The author provides a critical safety warning: Never turn on the VTX when the antenna is loose or not attached to the VTX, as this may cause a fire.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de 9g servo control horn arm

9g servo control horn arm

9g servo control horn arm Purpose This model is a control arm designed specifically for small-scale servos, often referred to as "itty bitty" servos. Practical Uses It is intended for use in radio control (RC) applications where small 9g servos are utilized. Included Parts - servo_arm_15mm.stl Printing and Assembly Guidance The author instructs to print the model at 86% scale to achieve a perfect fit.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
Vista de RC transmitter thumbstick knob upgrade

RC transmitter thumbstick knob upgrade

RC transmitter thumbstick knob upgrade Purpose Inspired by console gaming controllers, this model is intended to provide a more comfortable user experience compared to the standard spikey, tiny joystick knobs found on many R/C controllers, while still retaining grippiness. Practical Uses This model serves as an upgrade for R/C transmitter thumbsticks to improve ergonomics during use. Included Parts - controller replacement knob.stl Printing/Assembly Guidance Not provided.

Tecnología
Sin probar
Material
—
Dificultad
Sin especificar
