24 tagged models · Page 1 of 1

#cr-touch

Discover 3D models tagged cr-touch and check their print information, files and terms before downloading.Search this tag in the catalogue →
Vista de Ender 2 Pro CR-Touch Mount

Ender 2 Pro CR-Touch Mount

Ender 2 Pro CR-Touch Mount Purpose This model is designed to serve as a dedicated mount for the CR-Touch sensor on the Ender 2 Pro 3D printer. Practical Uses It is used to facilitate the installation and secure positioning of a CR-Touch probe on an Ender 2 Pro machine. Included Parts - E2Pro_BLTouchBracket_v5.stl Printing and Assembly Guidance No specific printing or assembly instructions are provided in the source documentation.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Pulling Pin Assistants for CR Touch of V3SE

Pulling Pin Assistants for CR Touch of V3SE

Pulling Pin Assistants for CR Touch of V3SE Purpose This tool is designed to assist with the "CR Touch error, please contact customer service" issue encountered on the Ender 3 V3 SE. It serves as a specialized handle to help users manually pull the CR-Touch pin up and down to address a stuck pin, providing an alternative to using pliers or other improvised tools. Practical Uses When the CR-Touch pin becomes stuck, users can use this assistant to repeatedly move the pin up and down. After performing this action, the printer can be restarted to attempt to resolve the error. Included Parts - CR-Touch-Attach-30mm.stl - CR-Touch-Attach-20mm.stl Printing Guidance To ensure proper functionality, the following print settings are recommended: - Filament Type: PETG or ABS - Infill: 100% - Layer Height: 0.1 mm - Print Speed: Below 30mm/s - Adhesion: No adhesion required

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Dragon Burner V8 CR-Touch Shroud

Dragon Burner V8 CR-Touch Shroud

Dragon Burner V8 CR-Touch Shroud Purpose This model provides CR-Touch support for the Dragon Burner V8 toolhead. It is designed to integrate bed leveling capabilities into the existing toolhead setup. Practical Uses It is used to mount a CR-Touch sensor to the Dragon Burner V8 toolhead. The author specifies the following probe offsets for configuration: X=-37.2, Y=10.1. Included Parts - Dragon Burner PFACatBody + Duct.stp.stl - Dragon Burner PFACatBody + Duct.stp Assembly Guidance According to the author, the assembly process for this component is the same as the regular fan shroud.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de CR Touch endstop mount

CR Touch endstop mount

Cr Touch endstop mount Purpose This model is a simple endstop mount designed for use with a CR Touch. It is also capable of functioning as a spacer. Practical Uses It serves as a mounting bracket for endstop components and can be utilized as a spacer in various configurations. The model is designed to be resized as needed to fit specific requirements. Included Parts - cr_touch_endstop.stl Printing and Assembly Guidance The author recommends printing this model using PETG material with 100% infill. Users should resize the model as needed for their specific application.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Ender 3 CR-Touch Mount

Ender 3 CR-Touch Mount

Ender 3 CR-Touch Mount Purpose This part is designed to facilitate the installation of a CR-Touch sensor. Its primary function is to allow the sensor to be positioned as close to the extruder as possible. Practical Uses This mount is intended for use with Ender 3 series printers to optimize the placement of the CR-Touch probe relative to the extruder assembly. Included Parts - MY_ender-3-cr-touch-mount.stl Printing and Assembly Guidance Not provided in the source text.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Dragon Burner Shroud w/ CR Touch w/o Ears

Dragon Burner Shroud w/ CR Touch w/o Ears

Dragon Burner Shroud w/ CR Touch w/o Ears Purpose This model is a remixed version of the Dragon Burner Shroud. It is specifically modified to remove the "ears" from the original design and to reposition the probe to a slightly higher position to prevent collisions. Practical Uses This shroud is intended for use with a Dragon Burner setup utilizing a CR Touch probe. The modifications are designed to address clearance issues and physical interference encountered with the standard version. Included Parts - CRTouchNOEars.stl Printing/Assembly Guidance Not provided in the source text.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Satsana Ender 3 Fan Duct for CR-Touch

Satsana Ender 3 Fan Duct for CR-Touch

Satsana Ender 3 Fan Duct for CR-Touch Purpose This model is a modified remix of the Satsana Fan Shroud/Duct by eric-anastas. It is specifically designed for the Ender 3 Pro to accommodate the Creality CR-Touch touch sensor using its standard hardware. Practical Uses This shroud serves as a 3D printer accessory to integrate a CR-Touch sensor with the fan duct system on an Ender 3 Pro. Included Parts - Satsana_CR-Touch_Remix.stl - cable cap.stl Printing and Assembly Guidance To print, the author suggests using a block object to prevent support generation on overlaps, ensuring only the bottom connecting sections are supported. While the author used a .16mm layer height, they noted that .2mm may also work. Reported print settings from the author: - Printer: Creality Ender 3 Pro - Rafts: No - Supports: Yes - Resolution: 200 - Infill: 38 - Filament: Overture PLA Post-printing, use an X-Acto blade or razor to remove supports from the connecting sections. This step is necessary to provide enough room for the CR-Touch bracket to install properly.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Manta MK2 CR Touch Mount Center Mount

Manta MK2 CR Touch Mount Center Mount

Manta MK2 CR Touch Mount Center Mount Purpose This model is designed for the Manta MK2 Ender V1/V2 system to allow the CR Touch to be used as the sensor instead of the BLTouch. Practical Uses It serves as a center mount for the CR Touch. When installing, the user suggests using the included spacer to adjust the CR Touch approximately 3mm above the nozzle to prevent crashes or incorrect Z-offset readings. Users may also use the 2mm side of the spacer or flush the CR Touch to the bed, though the 3mm spacing is recommended. Included Parts The files provided include the Manta CR Touch V3 STL and a 3MF file. Printing and Assembly Guidance For printing, the source suggests using PETG, ABS, or stronger materials rather than PLA. If using a high-temperature setup, use high-temperature resistant materials. Recommended print settings include a layer height of 1.6mm or 2.0mm and 100% infill. For ABS and PETG, a speed of 40mm/s is suggested. During assembly, installation involves using washers, screws through the CR Touch and bracket, followed by a washer and a nut. The source notes an X/Y offset of X= -1.8 and Y= -37.5.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de CR Touch with Dual Fan

CR Touch with Dual Fan

This model is designed as an alternative mounting solution for users who find that standard setups do not fit a CR Touch. The author notes that this specific configuration required an extension plate for use on an Ender 3 Pro. Practical uses include mounting a CR Touch or BL Touch on an Ender 3 Pro printer when standard dimensions are incompatible. Included parts: - CR Touch Extension.stl - Backplate with CR-Touch.stl

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Fan mount for Ender 2 Pro with CR touch bracket

Fan mount for Ender 2 Pro with CR touch bracket

Fan mount for Ender 2 Pro with CR touch bracket Purpose This model is a minimal fan mount designed specifically for the Ender 2 Pro. It serves a dual purpose by providing a mounting point for a fan while simultaneously including integrated support for a CR Touch probe. Practical Uses This component is intended for users looking to upgrade their Ender 2 Pro hardware to include a CR Touch probe alongside a functional fan mount. Please note that the author has not tested this specific configuration, as they did not upgrade the firmware or complete the physical connection of the probe. Included Parts * Fan Mount CR Touch.3mf Printing and Assembly Guidance No specific printing parameters or assembly instructions are provided in the source text. Users should be aware that functional testing regarding firmware compatibility and electrical connection is required, as the author did not perform these steps.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Hero Me + CR-Touch Modification for Ender 3

Hero Me + CR-Touch Modification for Ender 3

This model is a modified Hero Me setup designed for the Ender 3. It adapts the original Hero Me design to accommodate a Creality CR-Touch leveling probe instead of a standard BLTouch. The set also includes components for a 5015 radial fan cooling system. Users may use these specific files individually or combine them with the original Hero Me design. 1. Purpose: To provide a modified mounting solution for an Ender 3 that supports both a Creality CR-Touch probe and a 5015 radial fan. 2. Practical Uses: Upgrading Ender 3 cooling and leveling capabilities. 3. Included Parts: CR-Touch mount (CR-Touch.stl), 5015 fan pipes (5015_Pipes.stl), and a base (Base.stl). 4. Configuration Data: The author reports the Marlin probe offset as NOZZLE_TO_PROBE_OFFSET { -45.8, -10, 0 }.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Voron X Carriage for CR Touch

Voron X Carriage for CR Touch

This model is a modified Voron X carriage designed to be compatible with CR Touch leveling. The author modified the original model created by keja31 to accommodate the CR Touch sensor. Practical uses include upgrading a Voron X carriage to support CR Touch leveling systems. Included files: - CR touch.STL - CR-Touch-Dummy_extended.STEP

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de CR Touch shim

CR Touch shim

CR Touch shim Purpose This single shim is designed to provide clearance for wiring and the plug end when the CR Touch is installed using its included bracket. According to the author, this part is required on the Ender 3 V2 when utilizing a Spider V1.0 hotend. Practical Uses It serves as a spacer to ensure proper fitment and wire management during the assembly of the CR Touch probe on specific hotend configurations. Included Parts - 1 piece shim (CR Touch spacer.stl) Printing and Assembly Guidance The author reports printing the part with PLA, though they note there is no reason to believe the model would pose a problem with other materials. The author reports the part has been in use for 12+ hours of print time with no indications of pending failure.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Satsana 5015 duct for Ender 5 w/ Micro Swiss DD & CR Touch

Satsana 5015 duct for Ender 5 w/ Micro Swiss DD & CR Touch

This model is a remix of the Satsana duct designed specifically for an Ender 5 equipped with a Micro Swiss direct drive and a CR Touch ABL sensor. The design positions the ducts 1.5mm from the print surface to facilitate cooling. The CR Touch mount utilizes an x offset of -47 and a y offset of -9.5. 1. Purpose: To provide a customized cooling duct solution for specific Ender 5 hardware configurations. 2. Practical uses: Cooling optimization for Ender 5 printers using Micro Swiss direct drive and CR Touch sensors. 3. Included parts: ms-cr_satsana_duct.stl, ms-cr_cable_cap.stl, and ms-cr_satsana.step.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de BLtouch and CR-touch mount for Titan Aero with volcano hotend

BLtouch and CR-touch mount for Titan Aero with volcano hotend

This model provides mounts for BLtouch and CR-touch sensors specifically designed for use with a Titan Aero extruder and a Volcano hotend. Purpose The purpose of these mounts is to facilitate the installation of BLtouch or CR-touch auto-bed leveling sensors on a Titan Aero setup utilizing a Volcano-style hotend. Practical Uses These components are used in 3D printing setups where a Titan Aero extruder is paired with a Volcano hotend, allowing for the integration of touch-based leveling sensors to improve bed leveling accuracy. Included Parts The files included in this listing are: - volcano adapter.stl - cr touch volcano adapter.stl

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Remixed Parts of Chodec's Direct Drive for CR Touch

Remixed Parts of Chodec's Direct Drive for CR Touch

Remixed Parts of Chodec's Direct Drive for CR Touch Purpose This model provides remixed components designed to adapt Chodec's direct drive setup for use with a CR Touch instead of a BL Touch. The modifications specifically adjust the Ender 3 Pro main body and the fan duct to accommodate the sensor and include a notch for the wiring harness. Practical Uses These parts are intended for users looking to modify an Ender 3 Pro direct drive assembly to be compatible with CR Touch hardware. Included Parts - Fan Duct CR Touch.stl - E3P Main Body.stl Note: The author states these parts are "Not perfect."

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de CR TOUCH SPACERS FOR HEIGHT ADJUSTMENT

CR TOUCH SPACERS FOR HEIGHT ADJUSTMENT

Purpose These spacers are designed to adjust the height of a CR Touch probe. Practical Uses Users can stack the different sizes together to reach a specific required height or adjust the height within a slicer. Included Parts - Cr Touch Spacer 8mm.stl - Cr Touch Spacer 3mm.stl - Cr Touch Spacer 5mm.stl - Cr Touch Spacer 2mm.stl - Cr Touch Spacer 1mm.stl

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Ender 3 V3 SE CR Touch Spacer for KE/K1 Hotend

Ender 3 V3 SE CR Touch Spacer for KE/K1 Hotend

Purpose This spacer allows a CR Touch to be used with a V3 KE/K1 hotend when installed in a V3 SE printer. The design is based on the Volcano bracket by T3KPrinter. Practical Uses It serves as an adapter to accommodate the specific geometry of the KE/K1 hotend within the V3 SE setup. Included Parts V3SE-CRTouchSpacer.stl Assembly Guidance Installation requires two longer M3 screws because the original screws will not reach through the spacer. The author used 12mm screws, though 10mm screws may also work.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de Microswiss NG CR Touch Mount

Microswiss NG CR Touch Mount

Purpose: This mount is designed to attach a CR Touch probe to a Microswiss NG Toolhead when used on a custom X axis Ender 3 Pro. Practical Uses: To install the mount to the extruder stepper motor, two M3x25 screws and two M3 washers are required to replace the stock screws. Included Parts: - Microswiss NG Cr Touch Mount.3mf - Microswiss NG Cr Touch Mount (heatset insert version).3mf - microswiss ng cr touch mount.step Printing/Assembly Guidance: Print with the flange on the build plate using PETG or ABS for heat resistance. Recommended settings include a 0.2 mm layer height, infill greater than 20%, 3+ perimeters, and 3+ top/bottom layers. While supports are not required, the author notes they may improve the underside finish. The author provides CAD-calculated probe offsets (X: -47.25, Y: -10, Z: 2.110), but notes that Z offset must be manually recalibrated for individual machines and printed parts.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de CR Touch Bracket (Ender-3 V2 NEO)

CR Touch Bracket (Ender-3 V2 NEO)

Purpose This model is a recreation of the stock bracket used to hold the CR Touch on the Ender-3 V2 NEO printer. Practical Uses It serves as a replacement part for the original CR Touch mounting hardware. Included Parts - CR Touch Bracket.stl Printing and Assembly Guidance The author recommends printing with PETG, ABS, or ASA using 100% infill and a 0.2 resolution. The part works with the stock M3 screws provided with the printer.

Technology
Sin probar
material
—
Difficulty
Sin especificar
Vista de [FIX] CR-Touch error, please contact customer service

[FIX] CR-Touch error, please contact customer service

This model provides a discussion and a workaround for the Ender-3 V3 SE CR-Touch homing failure, where the probe pin fails to deploy at startup. The author suggests a "pre-parked" method: manually sliding the heated bed (Y-axis) all the way back and pushing the toolhead (X-axis) all the way to the left against the physical endstops before powering on the machine. This method aims to minimize motor current draw, relieve cable strain, and eliminate travel vibrations that may prevent the pin from deploying. Practical uses include troubleshooting CR-Touch deployment errors and providing a temporary solution to allow the printer to home and begin prints. The author suggests checking toolhead cable connections or using the provided file to print a cable strain relief bracket. Included files: - cr-touch-attach-30mm.stl

Technology
Sin probar
material
—
Difficulty
Sin especificar
